The SRP-2 Hydraulic Set Retrievable Packer is a single string packer to be used in vertical and deviated wellbores or in applications in which single or multiple packers are set after the wellhead has been installed. A modular shell and body design for pressure differential allows configuration as a single-string production packer. Its compact, modular design makes the SRP-2 Packer as an economical choice for production applications.

The SRP-2 Packer is installed with the completion tubing and is set by applying pressure to the tubing . Retrieve the SRP-2 is accomplished with lifting the tubing straightly. Once the tension on the tubing string exceeds the shear value of the release pins, the elements relax, and the slips disengage the casing. The packer shear-release mechanism can be adjusted in the field just before installation.


  • Application in the single-string completions, zonal isolation, vertical, deviated, or horizontal wellbores.

  • Bidirectional slips located below the sealing elements prevent the debris.

  • Eliminates tubing movement during installation.

  • Equalization system above the element.

  • Straight-pull to release the packer and the release shear value can be adjusted.

  • Can provide the various of materials and the thread connection.

  • Large bore.

  • Various metallic and non-metallic materials can be provided .



SRP-2 Hydraulic Setting Retrievable Packer

The SRP-2 Hydraulic Set Retrievable Packer is a single string packer to be used in vertical and deviated wellbores or in applications in which single or multiple packers are set after the wellhead has been installed......
