The  Landing Nipple offers an expanded versatility to downhole selection. Any desired numbers of SX Landing Nipple can be placed in the production string, thereby offering an unlimited number of positions for setting and locking surface controls. It may be used in the following applications:

  • Land blanking plugs to shut in well or test the production tubing.

  • Land velocity type safety valves.

  • Land equalizing check valves.

  • Land chokes to reduce the surface flowing pressure.

  • Land instrument hangers with geophysical devices such as pressure and temperature recorders

Features of SX Landing Nipple:

  • Reduce completion and production costs.

  • Nipple bore compatible with tubing size and weight to permit flow capacity.

Features of SXN Landing Nipple:

  • Full-opening packing bore,with a locking recess at the top of the Nipple and slightly restricted NO-GO at the bottom to prevent wirelinetools from dropping out of the tubing string and being lost.

  • All premium threads are available.



SX/SXN Landing Nipple

The  Landing Nipple offers an expanded versatility to downhole selection......
